Intel Core i5 12400 Tray

Processor
Processor Codename
Alder Lake
Packaging Type
Slide-in
Base Processor Power
65 W
Processor Manufacturer
Intel
Performance Cores
6
Efficient Cores
0
Processor Operating Modes
64-bit
Bus Type
DMI4
Maximum Number of DMI Lanes
8
Processor Threads
12
Maximum Memory Bandwidth Supported by Processor
76.8 GB/s
Maximum Turbo Power
117 W
Processor Boost Frequency
4.4 GHz
Number of Processor Cores
6
Performance Core Base Frequency
2.5 GHz
Processor Generation
12th Generation Intel® Core™ i5 Processors
Processor Cache Type
Smart Cache
Processor
i5-12400
Processor Family
Intel® Core™ i5
Processor Cache
18 MB
Performance Core Boost Frequency
4.4 GHz
ARK Processor identification
134586
Processor socket
LGA 1700
Memory
Maximum internal memory supported by the processor
128 GB
Maximum memory bandwidth
76.8 GB/s
Memory types supported by the processor
DDR4 SDRAM, DDR5 SDRAM
Memory channels
Dual-channel
Graphics
Integrated graphics adapter
Yes
Maximum dynamic frequency of the on-board graphics adapter
1.45 MHz
On-board graphics adapter supported outputs
Embedded DisplayPort (eDP), Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, DisplayPort 1.4, HDMI 2.1
On-board graphics adapter refresh rate at maximum resolution (HDMI)
60 Hz
Discrete graphics adapter
No
On-board graphics adapter DirectX version
12.0
Integrated graphics card model
Intel UHD Graphics 730
Multi-Format Codec Engines
1
Maximum resolution of the on-board graphics adapter (eDP - integrated flat panel display)
5120 x 3200 pixels
On-board graphics adapter device ID
0x4692 / 0x4682
Integrated graphics adapter maximum resolution (HDMI)
4096 x 2160 pixels
Number of supported displays (on-board graphics)
4
On-board graphics adapter OpenGL version
4.5
On-board graphics adapter refresh rate at maximum resolution (DisplayPort)
60 Hz
Discrete graphics card model
Not available
Number of processing units
24
On-board graphics adapter refresh rate at maximum resolution (eDP - integrated flat panel display)
120 Hz
Maximum resolution of the on-board graphics adapter (DisplayPort)
7680 x 4320 pixels
On-board graphics adapter base frequency
300 MHz
Features
Execute Disable Bit
Yes
Direct Media Interface (DMI) Revision
4.0
CPU Configuration (max)
1
Maximum Number of PCI Express Lanes
20
Supported Instruction Sets
SSE4.1, SSE4.2, AVX 2.0
Usage Conditions
PC/Client/Tablet
Scalability
1S
Idle States
Yes
Market Segment
Desktop
Commodity Classification System for Automated Tracking (CCATS)
G167599
Thermal Monitoring Technologies
Yes
PCI Express Slot Version
5.0, 4.0
PCI Express Configurations
1x16+1x4, 2x8+1x4
Export Control Classification Number (ECCN)
5A992.C
Embedded Options Available
Yes
Thermal Solution Specification
PCG 2020C
Processor Features
Enhanced Intel SpeedStep Technology
Yes
Intel® Enhanced Halt State
Yes
Intel® Quick Sync Video Technology
Yes
Intel® Optane™ Memory Ready
Yes
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0
Yes
Intel® AES New Instructions (Intel® AES-NI)
Yes
Intel® Speed ​​Shift Technology
Yes
Intel Turbo Boost Max Technology 3.0
No
Intel® Secure Key
Yes
Intel® Thread Director
No
Intel® Deep Learning Boost (Intel® DL Boost) on CPU
Yes
Intel® Hyper-Threading Technology (Intel® HT Technology)
Yes
Intel® Virtualization Technology for Direct I/O (VT-d)
Yes
Intel® Threat Detection Technology (TDT)
Yes
Intel® Control-flow Enforcement Technology (CET)
Yes
Intel® 64
Yes
Intel® VT-x with Extended Page Tables (EPT)
Yes
Intel® Standard Manageability (ISM)
Yes
Intel® Virtualization Technology (VT-X)
Yes
Intel® OS Guard
Yes
Intel® Volume Management Device (VMD)
Yes
Intel® Boot Guard
Yes
Mode-Based Execute Control (MBE)
Yes
Intel® Clear Video HD Technology for (Intel® CVT HD)
Yes
Intel® Turbo Boost Technology
2.0
Operating Conditions
Tjunction
100 °C
Maximum Operating Temperature
100 °C
Logistics Data
Commodity Tariff Number (HS)
8542310001
Technical Details
Target Market
Gaming
Status
Launched
Launch Date
Q1 2022
OpenCL Version
3.0
OpenGL Support
Yes
Packaging Data
Packaging Type
Slide-in
Weight and Dimensions
Processor Package Size
45 x 37.5 mm
Other features
Maximum RAM
128 GB
Graphics output
eDP 1.4b, DP 1.4a, HDMI 2.1
L2 buffer
7680 KB
