Intel Core i5 12400 Box

Processor
Processor Codename
Alder Lake
Base Processor Power
65 W
Processor Cache Type
Smart Cache
Efficient Cores
0
Processor Manufacturer
Intel
Maximum Turbo Power
117 W
Cooler Included
Yes
Maximum Memory Bandwidth Supported by Processor
76.8 GB/s
Processor Threads
12
Performance Core Boost Frequency
4.4 GHz
Number of Processor Cores
6
Processor Family
Intel® Core™ i5
Performance Cores
6
Performance Core Base Frequency
2.5 GHz
Processor Operating Modes
64-bit
Processor Generation
12th Generation Intel® Core™ i5 Processors
Processor Cache
18 MB
Processor Boost Frequency
4.4 GHz
Packaging Type
Box
Maximum Number of DMI Lanes
8
Processor Socket
LGA 1700
Bus Type
DMI4
ARK Processor Identification
134586
Processor
i5-12400
Memory
Maximum Memory Bandwidth
76.8 GB/s
Non-ECC
Yes
Maximum Internal Memory Supported by Processor
128 GB
Memory Types Supported by Processor
DDR4-SDRAM, DDR5-SDRAM
Memory Channels
Dual-Channel
Graphics
Discrete Graphics Card Model
Not Available
On-Board Graphics Adapter Supported Outputs
Embedded DisplayPort (eDP), Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, DisplayPort 1.4, HDMI 2.1
Maximum Dynamic Frequency of On-Board Graphics Adapter
1.45 MHz
On-Board Graphics Adapter Device ID
0x4692 / 0x4682
On-Board Graphics Adapter OpenGL Version
4.5
On-Board Graphics Adapter DirectX Version
12.0
Multi-Format Codec Engines
1
Onboard Graphics Adapter Refresh Rate at Maximum Resolution (eDP - Integrated Flat Panel Display)
120 Hz
Discrete Graphics Adapter
No
Number of Supported Displays (Onboard Graphics)
4
Built-in Graphics Adapters
Yes
Onboard Graphics Adapter Refresh Rate at Maximum Resolution (DisplayPort)
60 Hz
Integrated Graphics Adapter Maximum Resolution (HDMI)
4096 x 2160 pixels
Maximum Resolution of Onboard Graphics Adapter (eDP - Integrated Flat Panel Display)
5120 x 3200 pixels
Maximum Resolution of Onboard Graphics Adapter (DisplayPort)
7680 x 4320 pixels
Onboard Graphics Adapter Base Frequency
300 MHz
Built-in Graphics Card Model
Intel UHD Graphics 730
Number of Processing Units
24
Onboard Graphics Adapter Refresh Rate At maximum resolution (HDMI)
60 Hz
Features
CPU configuration (max)
1
Idle states
Yes
PCI Express configurations
1x16+1x4, 2x8+1x4
Supported instruction sets
SSE4.1, SSE4.2, AVX 2.0
Commodity classification system for automated tracking (CCATS)
G167599
Usage conditions
PC/Client/Tablet
Direct Media Interface (DMI) revision
4.0
Thermal monitoring technologies
Yes
Execute Disable Bit
Yes
Scalability
1S
PCI Express slot version
5.0, 4.0
Market segment
Desktop
Maximum number of PCI Express lanes
20
Export Control Classification Number (ECCN)
5A992.C
Thermal solution specification
PCG 2020C
Embedded Options Available
Yes
Processor Features
Intel Turbo Boost Max Technology 3.0
No
Intel® Enhanced Halt State
Yes
Intel® Control-flow Enforcement Technology (CET)
Yes
Intel® Virtualization Technology for Direct I/O (VT-d)
Yes
Intel® VT-x with Extended Page Tables (EPT)
Yes
Intel® OS Guard
Yes
Mode-Based Execute Control (MBE)
Yes
Intel® Quick Sync Video Technology
Yes
Intel® Volume Management Device (VMD)
Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU
Yes
Intel® Turbo Boost Technology
2.0
Intel® Optane™ Memory Ready
Yes
Intel® Boot Guard
Yes
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0
Yes
Enhanced Intel SpeedStep Technology
Yes
Intel® Secure Key
Yes
Intel® Virtualization Technology (VT-X)
Yes
Intel® Standard Manageability (ISM)
Yes
Intel® Clear Video HD Technology (Intel® CVT HD)
Yes
Intel® Threat Detection Technology (TDT)
Yes
Intel® Speed ​​Shift Technology
Yes
Intel® Thread Director
No
Intel® 64
Yes
Intel® AES New Instructions (Intel® AES-NI)
Yes
Intel® Hyper-Threading Technology (Intel® HT Technology)
Yes
Operating Conditions
Tjunction
100 °C
Maximum Operating Temperature
100 °C
Logistics Data
Commodity Tariff Number (HS)
85423119
Technical Details
Launch Date
Q1 '22
OpenGL Support
Yes
OpenCL Version
3.0
Status
Launched
Target Market
Gaming
Packaging Details
Packaging Type
Retail Box
Weight and Dimensions
Processor Package Size
45 x 37.5 mm
Other Features
Maximum RAM
128 GB
Graphics Output
eDP 1.4b, DP 1.4a, HDMI 2.1
L2 Buffer
7680 KB
