Intel Core i7 14700K Box

Processor
Processor Operating Modes
64-bit
Base Processor Power
125 W
Maximum Number of DMI Lanes
8
Stepping
B0
Efficient Base Core Frequency
2.5 GHz
Cooler Included
No
Efficient Core Boost Frequency
4.3 GHz
Processor Socket
LGA 1700
Processor Threads
28
Efficient Cores
12
Maximum Turbo Power
253 W
ARK Processor Identification
236783
Performance Cores
8
Processor Generation
Intel Core i7-14xxx
Processor Cache
33 MB
Processor Family
Intel® Core™ i7
Processor
i7-14700K
Processor Codename
Raptor Lake
Number of Processor Cores
20
Processor Manufacturer
Intel
Performance Core Boost Frequency
5.5 GHz
Processor Boost Frequency
5.6 GHz
Maximum memory bandwidth supported by the processor
89.6 GB/s
Packaging type
Box
Processor cache type
Smart Cache
Performance Core base frequency
3.4 GHz
Memory
Maximum internal memory supported by the processor
192 GB
ECC
Yes
Non-ECC
Yes
Memory channels
Dual-channel
Maximum memory bandwidth
89.6 GB/s
Memory types supported by the processor
DDR4-SDRAM, DDR5-SDRAM
Graphics
Number of processing units
32
On-board graphics adapter base frequency
300 MHz
On-board graphics adapter refresh rate at maximum resolution (DisplayPort)
60 Hz
On-board graphics adapter DirectX version
12.0
On-board graphics adapter device ID
0xA780
Discrete graphics adapter
No
On-board graphics adapter refresh rate at maximum resolution (HDMI)
60 Hz
Integrated graphics card model
Intel UHD Graphics 770
Integrated graphics adapter maximum resolution (HDMI)
4096 x 2160 pixels
On-board graphics adapter OpenGL version
4.5
Maximum resolution of the on-board graphics adapter (DisplayPort)
7680 x 4320 pixels
Number of supported displays (on-board graphics)
4
Multi-format codec engines
2
Discrete graphics card model
Not available
Maximum resolution of the on-board graphics adapter (eDP - integrated flat panel display)
5120 x 3200 pixels
Maximum dynamic frequency of the on-board graphics adapter
1600 MHz
Refresh rate of the on-board graphics adapter at maximum resolution (eDP - integrated flat panel display)
120 Hz
Built-in graphics adapter
Yes
On-board graphics adapter supported outputs
Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
Features
Export Control Classification Number (ECCN)
5A992C
Supported Instruction Sets
AVX 2.0, SSE4.1, SSE4.2
PCI Express Configurations
1x16+1x4, 2x8+1x4
Execute Disable Bit
Yes
Idle States
Yes
Commodity Classification System for Automated Tracking (CCATS)
740.17B1
Market Segment
Desktop
PCI Express Slot Version
4.0, 5.0
Direct Media Interface (DMI) Revision
4.0
Thermal Monitoring Technologies
Yes
Embedded Options Available
No
Thermal Solution Specification
PCG 2020A
Scalability
1S
Maximum Number of PCI Express Lanes
20
CPU Configuration (max)
1
Usage Conditions
Workstation, PC/Client/Tablet
Processor Features
Intel® VT-x with Extended Page Tables (EPT)
Yes
Intel® Volume Management Device (VMD)
Yes
Intel® Control-flow Enforcement Technology (CET)
Yes
Intel® AES New Instructions (Intel® AES-NI)
Yes
Intel® Virtualization Technology for Direct I/O (VT-d)
Yes
Intel® Speed ​​Shift Technology
Yes
Intel® Turbo Boost Max Technology 3.0 frequency
5.6 GHz
Intel Turbo Boost Max Technology 3.0
Yes
Intel® Hyper-Threading Technology (Intel® HT Technology)
Yes
Intel Enhanced SpeedStep Technology
Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU
Yes
Intel® Secure Key
Yes
Mode-Based Execute Control (MBE)
Yes
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0
Yes
Intel® OS Guard
Yes
Intel® Quick Sync Video Technology
Yes
Intel® Boot Guard
Yes
Intel® Clear Video HD Technology for (Intel® CVT HD)
Yes
Intel® Turbo Boost Technology
2.0
Intel® Standard Manageability (ISM)
Yes
Intel® 64
Yes
Intel® Thread Director
Yes
Intel® Virtualization Technology (VT-X)
Yes
Operating Conditions
Tjunction
100 °C
Logistics Data
Commodity Tariff Number (HS)
8542310001
Technical Details
OpenCL Version
3.0
Launch Date
Q4 2023
Status
Launched
Packaging Data
Packaging Type
Retail Box
Weight and Dimensions
Processor Package Size
45 x 37.5 mm
Other Features
Graphics Output
eDP 1.4b, DP 1.4a, HDMI 2.1
L2 buffer
28672 KB
Maximum RAM
192 GB
