Intel Core i7 14700K Tray

Processor
Efficient Core Boost Frequency
4.3 GHz
Processor
i7-14700K
Processor Socket
LGA 1700
Stepping
B0
Processor Cache
33 MB
Processor Operating Modes
64-bit
Efficient Cores
12
Packaging Type
Slot-in
Processor Cache Type
Smart Cache
Processor Threads
28
Efficient Core Base Frequency
2.5 GHz
Processor Family
Intel® Core™ i7
ARK Processor Identification
236783
Processor Boost Frequency
5.6 GHz
Performance Core Base Frequency
3.4 GHz
Maximum Memory Bandwidth Supported by Processor
89.6 GB/s
Processor Manufacturer
Intel
Performance Core Boost Frequency
5.5 GHz
Number of Processor Cores
20
Maximum Number of DMI Lanes
8
Processor Generation
Intel Core i7-14xxx
Base Processor Power
125 W
Maximum Turbo Power
253 W
Processor Codename
Raptor Lake
Performance Cores
8
Memory
Maximum Internal Memory Supported by Processor
192 GB
Maximum Memory Bandwidth
89.6 GB/s
Memory Channels
Dual Channel
Memory Types Supported by Processor
DDR4 SDRAM, DDR5 SDRAM
ECC
Yes
Graphics
Integrated Graphics Adapter
Yes
Onboard Graphics Adapter Refresh Rate at Maximum Resolution (DisplayPort)
60 Hz
Onboard Graphics Adapter DirectX Version
12.0
Onboard Graphics Adapter Refresh Rate at Maximum Resolution (eDP - Integrated Flat Panel Display)
120 Hz
Maximum Dynamic Frequency of Onboard Graphics Adapter
1600 MHz
Onboard Graphics Adapter Refresh Rate at Maximum Resolution (HDMI)
60 Hz
Maximum Resolution of Onboard Graphics Adapter (eDP - Integrated Flat Panel Display)
5120 x 3200 pixels
On-board graphics adapter device ID
0xA780
On-board graphics adapter supported outputs
Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
Discrete graphics card model
Not available
On-board graphics adapter OpenGL version
4.5
Embedded graphics card model
Intel UHD Graphics 770
Integrated graphics adapter maximum resolution (HDMI)
4096 x 2160 pixels
Multi-format codec engines
2
Number of processing units
32
Maximum resolution of the on-board graphics adapter (DisplayPort)
7680 x 4320 pixels
Discrete graphics adapter
No
Number of supported displays (on-board graphics)
4
On-board graphics adapter base frequency
300 MHz
Features
Scalability
1S
Usage Conditions
Workstation, PC/Client/Tablet
Supported Instruction Sets
AVX 2.0, SSE4.1, SSE4.2
Thermal Solution Specification
PCG 2020A
PCI Express Configurations
1x16+1x4, 2x8+1x4
Maximum Number of PCI Express Lanes
20
Execute Disable Bit
Yes
Export Control Classification Number (ECCN)
5A992C
Direct Media Interface (DMI) Revision
4.0
PCI Express Slot Version
4.0, 5.0
CPU Configuration (max)
1
Thermal Monitoring Technologies
Yes
Market Segment
Desktop
Commodity Classification System for Automated Tracking (CCATS)
740.17B1
Idle States
Yes
Embedded Options Available
No
Processor Features
Intel® OS Guard
Yes
Intel® Quick Sync Video Technology
Yes
Intel® Volume Management Device (VMD)
Yes
Mode-Based Execute Control (MBE)
Yes
Intel® Clear Video HD Technology for (Intel® CVT HD)
Yes
Intel® Thread Director
Yes
Intel® Control-flow Enforcement Technology (CET)
Yes
Intel® 64
Yes
Intel Turbo Boost Max Technology 3.0
Yes
Intel® Hyper-Threading Technology (Intel® HT Technology)
Yes
Intel Enhanced SpeedStep Technology
Yes
Intel® Turbo Boost Technology
2.0
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0
Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU
Yes
Intel® Virtualization Technology for Direct I/O (VT-d)
Yes
Intel® Standard Manageability (ISM)
Yes
Intel® Speed ​​Shift Technology
Yes
Intel® Boot Guard
Yes
Intel® Secure Key
Yes
Intel® Virtualization Technology (VT-X)
Yes
Intel® VT-x with Extended Page Tables (EPT)
Yes
Intel® Turbo Boost Max Technology 3.0 frequency
5.6 GHz
Intel® AES New Instructions (Intel® AES-NI)
Yes
Operating Conditions
Tjunction
100 °C
Logistics Data
Commodity Tariff Number (HS)
8542310001
Technical Details
Status
Launched
Launch Date
Q4 2023
OpenCL Version
3.0
Packaging Data
Packaging Type
Slide-in
Weight and Dimensions
Processor Package Size
45 x 37.5 mm
Other Features
L2 Buffer Memory
28672 KB
Maximum RAM Memory
192 GB
Graphics Exit
eDP 1.4b, DP 1.4a, HDMI 2.1
