Intel Core Ultra 5 225 Tray

Processor
Processor
225
Processor Cache
20 MB
Efficient Base Frequency
2.7 GHz
Processor Threads
10
Maximum Number of DMI Lanes
8
Performance Base Frequency
3.3 GHz
Performance Cores
6
Processor Operating Modes
64-bit
Processor Boost Frequency
4.9 GHz
Processor Generation
Intel Core Ultra (Series 2)
Efficient Core Boost Frequency
4.4 GHz
Processor Family
Intel Core Ultra 5
Base Power Consumption
65 W
AI Software Frameworks Supported by the CPU
DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Maximum Turbo Power Consumption
121 W
Processor Manufacturer
Intel
Processor Codename
Arrow Lake
Performance Core Boost Frequency
4.9 GHz
ARK Processor Identification
241070
Processor Socket
LGA 1851 (Socket V1)
Packaging Type
Slot-in
Efficient Cores
4
Processor Cache Type
Smart Cache
Number of Processor Cores
10
Neural Processing Unit (NPU)
Neural Processing Unit (NPU)
Intel AI Boost
Windows Studio Effects Support
Yes
AI Software Frameworks Supported by the NPU
DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Sparsity Support
Yes
GPU Performance up to
4 Tera Operations per Second
NPU Performance up to
13 Tera Operations per Second
Total Processor Performance up to
23 Tera Operations per Second
Memory
Memory Types Supported by Processor
DDR5 SDRAM
Memory Clock Speeds Supported by Processor
6400 MHz
Maximum Internal Memory Supported by Processor
192 GB
Memory Channels
Dual-Channel
Graphics
On-board graphics adapter refresh rate at maximum resolution (HDMI)
60 Hz
On-board graphics adapter base frequency
300 MHz
On-board graphics adapter DirectX version
12.0
On-board graphics adapter refresh rate at maximum resolution (DisplayPort)
60 Hz
Built-in graphics adapter
Yes
On-board graphics adapter OpenGL version
4.5
Discrete graphics card model
Not available
On-board graphics adapter supported outputs
HDMI 2.1, Embedded DisplayPort (eDP) 1.4b, DisplayPort 2.1
Number of supported displays (on-board graphics)
4
On-board graphics adapter refresh rate at maximum resolution (eDP - integrated flat panel display)
60 Hz
Discrete graphics adapter
No
On-board graphics adapter device ID
0x7D67
Xe cores
2
Maximum dynamic frequency of on-board Graphics Adapter
1800 MHz
Integrated Graphics Card Model
Intel Graphics
Features
Maximum Number of PCI Express Lanes
24
Usage Conditions
PC/Client/Tablet
Execute Disable Bit
Yes
PCI Express Slot Version
4.0, 5.0
Thermal Monitoring Technologies
Yes
Direct Media Interface (DMI) Revision
4.0
Market Segment
Desktop
Scalability
1S
Supported Instruction Sets
AVX 2.0, SSE4.1, SSE4.2
Idle States
Yes
Embedded Options Available
Yes
Processor Features
Mode-Based Execute Control (MBE)
Yes
Intel® Deep Learning Boost (Intel® DL Boost) on GPU
Yes
Intel® OS Guard
Yes
Intel® Thunderbolt 4
Yes
Intel® VT-x with Extended Page Tables (EPT)
Yes
Intel® Secure Key
Yes
Intel® Trusted Execution Technology
Yes
Intel® Control-flow Enforcement Technology (CET)
Yes
Intel® Virtualization Technology (VT-X)
Yes
Intel® Volume Management Device (VMD)
Yes
Intel® AES New Instructions (Intel® AES-NI)
Yes
Intel Enhanced SpeedStep Technology
Yes
Intel® 64
Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU
Yes
Intel® Standard Manageability (ISM)
Yes
Intel® Boot Guard
Yes
Intel® Thread Director
Yes
Intel® Quick Sync Video Technology
Yes
Intel® Speed ​​Shift Technology
Yes
Intel® Virtualization Technology for Direct I/O (VT-d)
Yes
Intel® Turbo Boost Technology
2.0
Operating Conditions
Maximum Operating Temperature
105 °C
Technical Details
Status
Launched
Launch Date
Q1 2025
OpenCL Version
3.0
Packaging Information
Packaging Type
Shelf Size
Other Features
Maximum RAM
192 GB
Graphics Output
DP2.1 UHBR20, HDM2.1 FRL 12GHz, eDP1.4b
L2 Buffer
22528 KB
