Thermaltake TR2 S 650W ATX 80+ Black

Power
AC Input Voltage
200 - 240 V
Energy Protection Features
Overcurrent, Overload, Overvoltage, Overheating, Short Circuit, Undervoltage
Combined Current (-12V)
3.6 W
Power Factor Correction (PFC) Filter
Active
Max. Output Current (+5V)
18 A
AC Input Frequency
50 Hz
Combined Current (+5Vsb)
12.5 W
Max. Output Current (+12V)
54.1 A
Hold Time
17 ms
Combined Current (+3.3V)
100 W
Combined Current (+12V)
650 W
Input Current
8 A
Max. Output Current (+5Vsb)
2.5 A
Max. Output Current (+3.3V)
18 A
Total Power
650 W
Max. Output Current (-12V)
0.3 A
Combined Current (+5V)
100 W
Connections and Interfaces
CPU Power Cable Length
65 cm
SATA Power Cable Length
500 mm
Cable Type
Non-modular
Number of PCI Express Power Connectors 6+2-pin
2
Motherboard Connector
20+4-pin ATX
Peripheral (Molex) Power Cable Length
500 mm
PCI Express Power Cable Length
50 cm
CPU Connector (4+4-pin)
Yes
Number of Molex Connectors 4-pin
4
Motherboard Power Cable Length
60 cm
Number of SATA Power Connectors
4
Performance
Power Supply Unit (PSU) Form Factor
ATX
80 Plus Certification
80 PLUS
Mean Time Between Failures (MTBF)
100,000 h
Purpose
PC / Server
Bearing Type
Hydraulic
Design
Cooling
Active
Product Color
Black
On/Off Switch
Yes
Number of Fans
1 Fan
Fan Diameter
12 cm
Operating Conditions
Relative Humidity During Operation
20 - 85%
Hygiene during storage
10–95%
Storage temperature range
-40–55 °C
Operating temperature
5–40 °C
Certifications
FCC/ICES/CB/cTUVus
Weight and dimensions
Depth
140 mm
Height
86 mm
Width
150 mm
Packaging information
Packaging type
Box
